2 Quick Start
30 Keysight 33210A Service Guide
To Output a Stored Arbitrary Waveform
There are five built-in arbitrary waveforms stored in non-volatile memory
.
The following steps show you how to output the built-in “exponential fall” waveform
from the front panel.
1 Select the arbitrary waveform function.
When you press the key to select the arbitrary waveform function,
a temporary message is displayed indicating which waveform is currently
selected (the default is “exponential rise”).
2 Select the active waveform.
Press the Select Wform softkey and then press the Built-In softkey to select
from the five built-in waveforms. Then press the Exp Fall softkey. The
waveform is output using the present settings for frequency, amplitude, and
offset unless you change them.
The selected waveform is now assigned to the key. Whenever you press
this key, the selected arbitrary waveform is output. To quickly determine which
arbitrary waveform is currently selected, press .
Arbitrary waveforms are optionally available with the 33210A (Option 002).
For information on creating a custom arbitrary waveform, refer to “To Create and
Store an Arbitrary Waveform” in the User’s Guide.
