Front-Panel Menu Operation 3
Keysight 33210A Service Guide 49
LAN Configuration
There are several parameters that you may need to set to establish network
communication using the LAN interface. Primarily, you will need to establish an IP
address. You may need to contact your network administrator for help in
establishing communication with the LAN interface.
1 Select the “I/O” menu.
Press
and then press the
I/O
softkey.
2 Select the “LAN” menu.
Press the LAN softkey.
You can select Modify Settings to change the LAN settings, or Current Config
to view the current LAN settings (including the MAC address).
Press
Modify Settings
.
From this menu, you can select Reset LAN to restart the LAN, IP Setup to set
an IP address and related parameters, DNS Setup to configure DNS, or
Password to set a password for the Web Server Interface.
