Quick Start 2
Keysight 33210A Service Guide 19
To Prepare the Function Generator for Use
1 Check the list of supplied items.
Verify that you have received the following items with your instrument. If
anything is missing, please contact your nearest Keysight Sales Office.
– Power cord (for country of destination).
– Certificate of Calibration.
– Keysight 33210A Product Reference CD (product software, programmi
ng
examples, and manuals).
– Keysight Automation-Ready CD (Keysight IO Libraries Suite).
– USB 2.0 cable.
2 Connect the power cord and turn on the function generator.
The instrument runs a short power-on self test, which takes a few seconds.
When the instrument is ready for use it displays a message about how to
obtain help, along with the current GPIB address and USB identification
string. The function generator powers up in the sine wave function at 1 kHz
with an amplitude of 100 mV peak-to-peak (into a 50Ω termination).
At power-on, the
Output
connector
is disabled. To enable the Output
connector, press the key
.
If the function generator does not turn on, verify that the power cord is
firmly
connected to the power receptacle on the rear panel (the power-line
voltage is
automatically sensed at power-on). You should also make sure
that the function
generator is connected to a power source that is energized
. Then, verify that the
function generator is turned on.
All of the 33210A product documentation is provided on the Keysight 33210A
Product Reference CD that comes with the product.
If the power-on self test fails, “Self-Test Failed” is displayed along with an error
code. See the Keysight 33210A Service Guide for information on error codes,
and for
instructions on returning the function generator to Keysight for service.
