Front-Panel Menu Reference
This section gives an overview of the front-panel menus. The remainder of this
chapter contains examples of using the front-panel menus.
Configure the modulation parameters for AM, FM, and PWM.
– Select the modulation type.
– Select an internal or external modulation source.
– Specify AM modulation depth, modulating frequency, and modulation shape.
–
Specify FM frequency deviation, modulating frequency, and modulation shape.
– Specify PWM deviation, modulating frequency, and modulation shape.
Configure the parameters for frequency sweep.
– Select linear or logarithmic sweeping.
– Select the start / stop frequencies or
center / span frequencies.
– Select the time in seconds required to complete a sweep.
– Specify a marker frequency.
– Specify an internal or external trigger source for the sweep.
– Specify the slope (rising or falling edge) for an external trigger source.
– Specify the slope (rising or falling edge) of the “Trig Out” signal.
