Calibration Procedures 4
Keysight 33210A Service Guide 77
3 On the power meter, use the Relative Power function to set the current reading
as the reference value. This will allow you to compare future measurement
results in dB.
4 Set the power meter offset to equal the 100kHz_20dB_offset value previously
calculated. This sets the power meter to directly read the flatness error
specification relative to 1 kHz. 100kHz_20dB_offset is calculated on the
"Amplitude and Flatness Verification Worksheet".
5 Set the instrument to each output described in the table below and measure
the output amplitude with the power meter.
6 Compare the measured output to the test limits shown in the table.
Keysight 33210A Measurement
Output Setup Function Amplitude Frequency Nominal Error
Q 50 Ω Sine Wave +23.90 dBm 100.000 kHz 0 dB ± 0.1 dB
50 Ω Sine Wave +23.90 dBm 200.000 kHz 0 dB ± 0.2 dB
50 Ω Sine Wave +23.90 dBm 500.000 kHz 0 dB ± 0.2 dB
50 Ω Sine Wave +23.90 dBm 2.000 MHz 0 dB ± 0.2 dB
50 Ω Sine Wave +23.90 dBm 3.000 MHz 0 dB ± 0.2 dB
Q 50 Ω Sine Wave +23.90 dBm 4.000 MHz 0 dB ± 0.2 dB
50 Ω Sine Wave +23.90 dBm 5.000 MHz 0 dB ± 0.2 dB
50 Ω Sine Wave +23.90 dBm 8.000 MHz 0 dB ± 0.3 dB
Q 50 Ω Sine Wave +23.90 dBm 10.000 MHz 0 dB ± 0.3 dB
