Programming Examples
Pulsed Sweep Measurements
Pulsed Sweep Measurements
To perform pulsed sweep measurements, use the following commands.
NOTE Measurement channel performs measurement so that the pulse width and pulse
period are kept. The integration time is automatically set by the instrument, and you
cannot change. For the Keysight E5270B, note that the high-resolution ADC cannot
be used for the pulsed measurements. The AAD/AIT/AV/WT command settings are
ignored.
Function Command Parameters
Enables channels CN [chnum ... [,chnum] ... ]
Disables channels CL [chnum ... [,chnum] ... ]
Sets filter ON/OFF [FL] mode[,chnum ... [,chnum] ... ]
Sets series resistor ON/OFF [SSR] chnum[,mode]
Sets pulse timing parameters PT hold,width,period [,tdelay]
Sets auto abort function [WM] abort[,post]
Sets pulsed sweep source PWV chnum,mode,range,base,start,
stop, step[,comp]
PWI
Sets synchronous sweep source
a
[WSV] chnum,range,start,stop
[,comp[,Pcomp]]
[WSI]
Forces constant voltage DV, TDV chnum,range,output
[,comp[,polarity[,crange]]]
Forces constant current DI, TDI
Sets voltage measurement range [RV] chnum,range
Sets current measurement range [RI] chnum,range
[RM] chnum,mode[,rate]
Selects measurement mode MM 4,chnum
Sets SMU operation mode [CMM] chnum,mode
Executes measurement XE
a. The WSV/WSI command must be entered after the PWV/PWI command.
