3- 40 Keysight E5260/E5270 Programming Guide, Edition 4
Programming Examples
Linear Search Measurements
Linear Search Measurements
To perform linear search measurements, use the following commands.
The LSV and LSI commands clear the previous source settings.
Send the LSI command before sending the LSSI command.
Send the LSV command before sending the LSSV command.
The LSI/LSSV commands or LSV/LSSI commands cannot be used together.
Function Command Parameters
Enables channels CN [chnum ... [,chnum] ... ]
Disables channels CL [chnum ... [,chnum] ... ]
Sets filter ON/OFF [FL] mode[,chnum ... [,chnum] ... ]
Sets series resistor ON/OFF [SSR] chnum[,mode]
Sets integration time
(Keysight E5270B can use
AAD/AIT instead of AV.)
[AV] number[,mode]
[AAD] chnum[,type]
[AIT] type,mode[,N]
Sets measurement mode MM 14
Selects output data [LSVM] output_data
Sets timing parameters [LSTM] hold,delay
Sets auto abort function [LSM] abort[,post]
Sets current search or
voltage search condition
LGI or
LGV
chnum,mode,range,target
Sets voltage source or
current source
LSV or
LSI
chnum,range,start,stop,step
[,comp]
Sets synchronous voltage
source or current source
[LSSV] or
[LSSI]
chnum,polarity,offset[,comp]
Forces constant voltage DV, TDV chnum,range,output
[,comp[,polarity[,crange]]]
Forces constant current DI, TDI
Executes measurement XE
