Keysight E5260/E5270 Programming Guide, Edition 4 3- 57
Programming Examples
Using Trigger Function
The following commands are also available to send a trigger or wait for an external
trigger input. Refer to
“Using Trigger Function” on page 2-35.
Command Function and Syntax
OS Causes the Keysight E5260/E5270 to send a trigger signal from
the Ext Trig Out terminal.
OS
OSX
a
a. Enter the TGP command to set the trigger port.
Causes the Keysight E5260/E5270 to send a trigger signal from
the specified port.
OSX port[,level]
WS Enters a wait state until the Keysight E5260/E5270 receives an
external trigger via the Ext Trig In terminal.
WS [mode]
WSX
a
Enters a wait state until the Keysight E5260/E5270 receives an
external trigger via the specified port.
WSX port[,mode]
PA Pauses command execution or internal memory program
execution until the specified wait time has elapsed, or until a
trigger is received from the Ext Trig In terminal if the TM3
command has been entered.
PA [wait]
PAX
a
Pauses command execution or internal memory program
execution until the specified wait time has elapsed, or until a
trigger is received from the specified port if the TM3 command
has been entered.
PAX port[,wait]
TGP Sets trigger port to the specified terminal.
TGP port,terminal,polarity[,type]
TM3 Uses an external trigger to release the PA/PAX command state or
to start measurement when the E52570 is not in the PA/PAX/
WS/WSX command state.
