4- 46 Keysight E5260/E5270 Programming Guide, Edition 4
Command Reference
Command Reference
CN
This command enables the specified channels by setting the output switches to ON.
Then the power consumption is 0 W.
WARNING SETTING THE OUTPUT SWITCH TO "ON" ENABLES THE CHANNEL
TO FORCE DANGEROUS VOLTAGES.
WHEN THE CHANNEL IS NOT IN USE, SET THE OUTPUT SWITCH TO
"OFF" WHENEVER POSSIBLE.
Execution
Conditions
No channel may be in the HIGH VOLTAGE state (forcing more than ±42 V, or
voltage compliance set to more than ±42 V).
Syntax CN [chnum[,chnum...[,chnum]...]]
A maximum of eight channels can be set.
Parameters chnum : Channel number. The value must be slot number where the module has
been installed. Integer expression. 1 to 8 (1 and 5 are not available for
HPSMU). See
Table 4-1 on page 4-9.
If you specify multiple chnums, the E5260/E5270 sets the output switches to ON, in
the specified order.
If you do not specify chnum, the E5260/E5270 sets all output switches to ON, in the
order from lower to higher slot number.
Remarks The CN command sets the specified channels to the following conditions:
If the output switch of the specified channel is already set to ON, no action is
performed by the CN command.
Example
Statements
OUTPUT @E5270;"CN"
OUTPUT @E5270;"CN 1,2,3,5"
Item Setting Item Setting
Output Switch ON I Compliance 100 μA
Source Mode Vo l t a ge I Range 100 μA
Output Voltage 0 V Filter Not changed
V Range 20 V Series Resistor Not changed
