Keysight Technologies E5260 Series

Keysight E5260/E5270 Programming Guide, Edition 4 4- 9
Command Reference
Command Parameters
Command Parameters
The parameters used by several commands are explained in this section.
• “Channel Number”
• “Voltage Measurement Ranging Type”
• “Current Measurement Ranging Type”
• “Voltage Output Ranging Type”
• “Current Output Ranging Type”
• “Voltage Source Setup Parameters for
DV/TDV/BDV/WV/WSV/WNX/PV/PWV/LSV/BSV Commands”
• “Current Source Setup Parameters for
DI/TDI/WI/WSI/WNX/PI/PWI/LSI/BSI Commands”
In the following tables, the command parameters are put in italics such as chnum.
Table 4-1 Channel Number
Mainframe chnum Description
E5270B 2, 3, 4, 6, 7, 8
HPSMU
a
in the slot specified by chnum.
a. HPSMU uses two slots. Then chnum must be the greater slot number.
For example, if it is installed in slot 3 and 4, chnum must be 4.
1 to 8 MPSMU in the slot specified by chnum.
1 to 8 HRSMU in the slot specified by chnum.
E5260A 2, 3, 4, 6, 7, 8
HPSMU
a
in the slot specified by chnum.
1 to 8 MPSMU in the slot specified by chnum.
E5262A 1 MPSMU in slot 1.
2 MPSMU in slot 2.
E5263A 1 MPSMU in slot 1.
2 HPSMU.
