Keysight E5260/E5270 Programming Guide, Edition 4 4- 15
Command Reference
Command Parameters
Table 4-7 Current Source Setup Parameters for
DI/TDI/WI/WSI/WNX/PI/PWI/LSI/BSI
Commands
Output
range
(actually
used)
Setting
resolution
in A
current, start,
stop, base, or
pulse in
A
Maximum Vcomp value in V
E5280B E5281B E5287A E5290A E5291A
1 pA 1E-15 0 to ± 1.15 E-12 NA NA ±100 NA NA
10 pA 5E-15 0 to ± 11.5 E-12 ±100
100 pA 5E-15 0 to ± 115 E-12 ±100
1 nA 50E-15 0 to ± 1.15 E-9 ±200 ±100 ±100
10 nA 500E-15 0 to ± 11.5 E-9 ±200 ±100 ±100
100 nA 5E-12 0 to ± 115 E-9 ±200 ±100 ±100 ±200 ±100
1 μA 50E-12 0 to ± 1.15E-6 ±200 ±100 ±100 ±200 ±100
10 μA 500E-12 0 to ± 11.5E-6 ±200 ±100 ±100 ±200 ±100
100 μA 5E-9 0 to ± 115E-6 ±200 ±100 ±100 ±200 ±100
1 mA 50E-9 0 to ± 1.15E-3 ±200 ±100 ±100 ±200 ±100
10 mA 500E-9 0 to ± 11.5E-3 ±200 ±100 ±100 ±200 ±100
100 mA 5E-6 0 to ± 20E-3 ±200 ±100 ±100 ±200 ±100
to ± 50E-3 ±200 ±40 ±40 ±200 ±40
to ± 100E-3 ±100 ±20 ±20 ±100 ±20
to ± 115E-3 ±100 NA NA ±100 ±20
200 mA 10E-6 0 to ± 20E-3 NA NA ±100
to ± 50E-3 ±40
to ± 200E-3 ±20
1 A 50E-6 0 to ± 50E-3 ±200 ±200 NA
to ± 125E-3 ±100 ±100
to ± 500E-3 ±40 ±40
to ± 1 ±20 ±20
