4- 8 Keysight E5260/E5270 Programming Guide, Edition 4
Command Reference
Command Summary
External
Trigger
TGP Enables the trigger function for a terminal.
TGPC Clears the trigger setting of the specified ports.
TGSI Selects the sweep step first or last that ignores the Start Step Output Setup
trigger input set by the TGP
port,1,polarity,2 command.
TGSO Selects the trigger type, edge or gate, for the Step Output Setup
Completion trigger output set by the TGP
port,2,polarity,2 command.
TGXO Selects the trigger type, edge or gate, for the Measurement Completion
trigger output set by the TGP
port,2,polarity,1 command.
TGMO Selects the trigger type, edge or gate, for the Step Measurement
Completion trigger output set by the TGP
port,2,polarity,3 command.
OS/OSX Causes the E5260/E5270 to send a trigger signal from a trigger output
terminal.
WS/WSX Enters a wait state until the E5260/E5270 receives an external trigger via
a trigger input terminal.
TM3 Enables use of an external trigger to release the PA/PAX state, or to start
measurement if the E5260/E5270 has not been set to the
PA/PAX/WS/WSX state. Or enables trigger set by the TGP
port,terminal,polarity,1.
Digital I/O
port
ERM Changes the digital I/O port assignments.
ERS? Returns the digital I/O port status.
ERC Changes the output status of the digital I/O port.
Display and
keyboard
RED Enables or disables the measurement data display and the setup data
display in the remote mode.
DFM Selects the data display format, scientific or engineering.
SPA Selects the parameter displayed in the Source Data display area.
MPA Selects the parameter displayed in the Measurement Data display area.
SCH Selects the source channel for the data is displayed on the LCD.
MCH Selects the measurement channel for the data is displayed on the LCD.
KLC Locks or unlocks the front panel keys.
Category Command Summary
