Command Reference
Command Parameters
Table 4-2 Voltage Measurement Ranging Type
range
a
a. If the measurement channel forces voltage, the channel uses the voltage output range regardless
of the range value.
Ranging type
for measurement mode
without pulse
for measurement mode
that uses pulse
0 Auto ranging Measurement channel uses
the minimum range that
covers the compliance
value.
5, for E5281B/E5287A 0.5 V limited auto ranging
50, for E5281B/E5287A 5 V limited auto ranging
20 or 11 2 V limited auto ranging
200 or 12 20 V limited auto ranging
400 or 13 40 V limited auto ranging
1000 or 14 100 V limited auto ranging
2000 or 15, for E5280B/E5290A 200 V limited auto ranging
-5, for E5281B/E5287A 0.5 V range fixed
-50, for E5281B/E5287A 5 V range fixed
-20 or -11 2 V range fixed
-200 or -12 20 V range fixed
-400 or -13 40 V range fixed
-1000 or -14 100 V range fixed
-2000 or -15, for E5280B/E5290A 200 V range fixed
