Command Reference
Command Reference
DZ
The DZ command stores the settings (V/I output values, V/I output ranges, V/I
compliance values, and series resistor setting) of the specified channels, and sets the
channels to 0 V. The settings can be recovered by using the RZ command. The
stored settings are cleared by using a device clear (HP BASIC CLEAR) command,
*RST, RZ, CL, CA, or *TST?.
Syntax DZ [chnum[,chnum...[,chnum]...]]
A maximum of eight channels can be set.
Parameters chnum : Channel number. The value must be slot number where the module has
been installed. Integer expression. 1 to 8 (1 and 5 are not available for
HPSMU). See
Table 4-1 on page 4-9.
If you specify multiple chnums, the E5260/E5270 sets the channels to 0 V in the
specified order.
If you do not specify chnum, the DZ command applies 0 V to all channels where the
output switch is set to ON, in order from higher (output or measurement range) to
lower voltage range.
Remarks The DZ command sets the specified channels to the following conditions:
Example
Statements
OUTPUT @E5270;"DZ 1,2,3"
Item Setting Item Setting
Output Switch ON I Range See next table
Source Mode Voltage Compliance See next table
Output Voltage 0 V Filter Not changed
V Range Not changed Series Resistor Not changed
Previous range
a
a. Range value that was set before the DZ command.
I Range I Compliance
1 nA to 100 μA same as previous range range value
over 100 μA 100 μA 100 μA
