Keysight E5260/E5270 Programming Guide, Edition 4 1- 35
Programming Basics
Data Output Format
E Status. Three bits.
• Status for Source_data:
Priority of appearance is 001<010.
• Status for Data, Data_search, or Data_sense. See Table 1-4.
Priority of appearance is as follows:
• For the quasi-pulsed spot measurement: 0<1<2<3<4<6 or 7
• For other measurement: 0<6<7<1<2<3<4<5
F Channel number of the measurement/source channel. Five bits.
E Explanation
001 Data is for the first or intermediate sweep step.
010 Data is for the last sweep step.
F Explanation
00001 (1) Channel 1.
00010 (2) Channel 2.
00011 (3) Channel 3.
00100 (4) Channel 4.
00101 (5) Channel 5.
00110 (6) Channel 6.
00111 (7) Channel 7.
01000 (8) Channel 8.
11111 (31) Invalid data is returned.
