2- 32 Keysight E5260/E5270 Programming Guide, Edition 4
Remote Mode Functions
Trigger Function
PA/PAX/WS/WSX
Commands
The commands put the E5260/E5270 in the trigger wait state. The E5260/E5270 can
recover from the wait state if an external trigger is sent to a trigger input port. You
can use the commands regardless of the trigger type.
If you use the PA or PAX command to put the E5260/E5270 in the trigger wait state,
send the TM3 command before the PA or PAX command.
Table 2-3 Type of Trigger Input
Type E5260/E5270 Operation by Input Trigger
Command
a
a. t selects trigger input terminal, Ext Trig In or a digital I/O path.
p selects positive or negative logic of the trigger.
m selects Case 1 or Case 2 of the trigger type 2 (see Figure 2-20).
1 Starts the measurement specified by the MM
command.
TGP t,1,p,1
TM3
2 The sweep source starts to set the sweep step output.
The pulse source starts to set the pulsed output.
This trigger type is available for the staircase sweep,
pulsed spot, pulsed sweep, staircase sweep with pulsed
bias, or multi channel sweep measurement.
TGP t,1,p,2
TGSI m
3 Waits for the measurement trigger delay, and starts the
sweep step measurement.
This trigger type is available for the staircase sweep
and multi channel sweep measurement.
TGP t,1,p,3
