Keysight Technologies M9036A

2 Keysight M9036A PXIe Embedded Controller User Guide
Introduction M9036A at a Glance
M9036A at a Glance
The following figure shows the front panel for the M9036A PXIe Controller.
Detailed information about the module follows in this manual.
Figure 1 M9036A Embedded Controller Front Panel
LED Indicators
SMB Trigger
LAN (GbE)
Port #2
USB Ports
Reset Button
DVI-I Connector
ExpressCard 34
Connector
GPIB
Connector
Connector
Lever Lock Release Button
(press red button down
before moving black
ejector/injector handle)
LAN (GbE)
Port #1
(allows Wake on LAN)
