Keysight M9036A PXIe Embedded Controller User Guide 63
Replacing the Hard Drive Service
6 To replace the hard drive, reverse the preceding steps. Place the new hard
drive in the carrier and carefully slide the hard drive into the empty socket.
7 When you power up the chassis, the controller BIOS should automatically
detect the new hard drive. If you created the disk image on the new hard
drive, the controller should boot normally and be ready to operate. If you
created the image on an external drive, you will need to boot from the
emergency CD or USB stick and then use the disk imaging software to
transfer the operating system, user settings, application software, data files,
etc. to the new hard drive.
If you feel resistance when installing the new hard drive, do not force it. You m
If you feel resistance as you install the new hard drive, do not
force it. You may have the drive upside down. Damaging the signal
pins may render the drive useless.
If the SSD is removed from the M9036A, do not insert the
controller into a chassis and power it up. Always install the SSD
before applying power to the M9036A. If you do not, then the
SATA selection is eliminated from the boot option list. If the SSD is
then reinstalled, then at boot the SATA selection will no be the
first option to boot from. The boot order should be changed so
that SATA is the first option.
