Keysight Technologies N5193A User Manual

Keysight Agile Signal Generator Service Guide 49
Troubleshooting
Table 1-3 Device Output Power - 20 GHz Models
Output Frequency (GHz)
≥ 0.01 to < 1.43 ≥ 1.43 to < 2.85 ≥ 2.85 to < 5.70 ≥ 5.70 to < 11.4 ≥ 11.4 to < 20.0
N Multiplier 1 2 4 8 16
A17J5
Frequency ≥ 0.01 to < 1.43 ≥ 1.43 to < 2.85 ≥ 2.85 to < 5.70 ≥ 5.70 to < 11.4 ≥ 11.4 to < 20.0
Power > 15.5 dBm > 18.5 dBm > 18.0 dBm > 18.0 dBm > 17.0 dBm
A18J4
Frequency ≥ 0.01 to < 1.43 ≥ 1.43 to < 2.85 N/A N/A N/A
Power > 17.0 dBm > 20.0 dBm N/A N/A N/A
A17J2
Frequency N/A ≥ 1.43 to < 2.85 N/A N/A N/A
Power N/A > 8.5 dBm N/A N/A N/A
A16J4
Frequency N/A ≥ 1.43 to < 2.85 N/A N/A
Power N/A +15 dBm +16 dBm N/A N/A
A16J10
Frequency N/A N/A N/A ≥ 5.70 to < 11.4 ≥ 11.4 to < 20.0
Power N/A N/A N/A > 2.0 dBm > 4.0 dBm
A14J2
Frequency N/A ≥ 0.7125 to <
1.425
≥ 0.7125 to < 1.425 ≥ 0.7125 to < 1.425 ≥ 0.715 to < 1.25
Power N/A >
3.0 dBm > 3.0 dBm > 3.0 dBm > 3.0 dBm
A14J1
Frequency ≥ 0.01 to < 1.43 N/A N/A N/A N/A
Power > 8.0 dBm N/A N/A N/A N/A
A12J102
Frequency ≥ .01 to < 1.43 ≥ 0.715 to < 1.425 ≥ 0.7125 to < 1.425 ≥ 0.7125 to < 1.425 ≥ 0.7125 to < 1.25
Power > 10 dBm > 10 dBm > 10 dBm > 10 dBm > 10 dBm
