Keysight E5071C ENA Series User Manual

Keysight E5071C ENA Series RF Network Analyzers 47
Troubleshooting
System Recovery
HDD Revision: CN924 or below
Step 1. Shut down the E5071C.
Step 2. Disconnect all of the USB device from the USB ports.
Step 3. Connect the keyboard to the E5071C.
Step 4. Press the standby switch of the E5071C to turn it on.
Step 5. When the screen as shown in the figure below appears, press of the
keyboard.
You need a keyboard for this operation.
Press F11 only once. If you press F11 twice or more and a screen which is
not mentioned in this manual appears, reboot the instrument and restart
the process from the first.
After several seconds, the next screen appears automatically even if you
do not press any key, so do not miss it.
After Step 5, if the E5071C freezes with the cursor does not blink, turn the
off and remove unnecessary USB devices. Then, replace the keyboard with
a PS/2 keyboard to execute the process again.
F11
e5071cse1055
Starting Acronis Loader...
Press F11 for Acronis Startup Recovery Manager...

Keysight E5071C ENA Series Specifications

General

Number of Ports	2 or 4
Dynamic Range	>123 dB (typical)
Connectivity	LAN, USB, GPIB
Display	10.4-inch LCD
Trace Noise	0.004 dB rms
Impedance	50 Ohm
Weight	20 kg
Dimensions	426 mm × 177 mm × 407 mm
