3 Spectrum Analyzer Mode
3.6 Power Stat CCDF Measurement
Counts
Sets the accumulated number of sampling points for data acquisition. The range is
1.000 kpt (k point) to 2.00000 Gpt (G point) with 1 kpt resolution.
Remote Command
[:SENSe]:PSTatistic:COUNts <integer>
[:SENSe]:PSTatistic:COUNts?
Example
:PST:COUN 5001
:PST:COUN?
Couplings Coupled to "Meas Cycles" on page 1206, by:
Counts = Meas Cycles * SamplingFrequency * "Meas Interval" on page 1206
Preset 10000000
State Saved Saved in instrument state
Min/Max 1000/2000000000
Meas Cycles
Set the number of measurement cycles to calculate power statistic data. This
number is coupled to "Counts" on page 1206, by:
Meas Cycles = Counts / (Sampling Frequency * Meas Interval)
When the Counts value cannot be divided by (Sampling Frequency * "Meas Interval"
on page 1206), this value is displayed as a decimal fraction.
Remote
Command
[:SENSe]:PSTatistic:SWEep:CYCLes <real>
[:SENSe]:PSTatistic:SWEep:CYCLes?
Example
:PST:SWE:CYCL 1001
:PST:SWE:CYCL?
Preset Depends on the sampling frequency
Min 0.001
Max Depends on the sampling frequency
Meas Interval
Sets the number of data points to be used as the measurement interval. This value
couples to "Counts" on page 1206, as:
Meas Interval = Counts / ("Meas Cycles" on page 1206 * Sampling Frequency)
Remote
[:SENSe]:PSTatistic:SWEep:TIME <time>
1206 Spectrum Analyzer Mode User's &Programmer's Reference
