3 Spectrum Analyzer Mode
3.13 Phase and Amplitude vs Time Measurement
Meas Mode Preset
PAVT 5GNR, VMA OFF
DDEM VMA OFF
OFDM VMA OFF
SAN SA ON
HARM SA ON
3.13.4 BW
For this measurement, bandwidth is determined by the algorithm, and is not user-
adjustable.
3.13.5 Display
Opens the Display menu, which lets you configure display items for the current
Mode, Measurement View or Window.
3.13.5.1 Meas Display
Contains controls for setting up the display for the current Measurement, View or
Window.
Display Type
Allows you to display Phase and Amplitude traces in absolute values, or values
relative to the 1
st
sample point’s phase and amplitude. The 1
st
sample point’s phase
and amplitude are different from the Relative Baseline values, which only reflect the
segment averaged phase and amplitude values. Setting Display Type to RELative
enables the phase and amplitude traces to start from 0 degree and 0 dB, so there is
no need to adjust scale or reference between measurements.
Remote Command
:DISPlay:PAVTime:TYPE ABSolute | RELative
:DISPlay:PAVTime:TYPE?
Example
:DISP:PAVT:TYPE REL
:DISP:PAVT:TYPE?
Preset
ABSolute
State Saved Yes
Range
ABSolute|RELative
Spectrum Analyzer Mode User's &Programmer's Reference 1997
