6-2 TS-5020 Automotive Electronics Functional Test System Wiring Guide and Hardware Reference
6 Replaceable And Spare Parts
Keysight E2230A Replaceable Parts
Table 6-1 PC Kits
Part Number Description
E2235B PC-IND CTLR CR2 DUO DT 3.0GHZ IPC-610 (5067-4802)
Optical Wheel Mouse Mouton 2D Combo with Ferrite-Core inside
(1150-7913)
OEM keyboard SK-1688 (1150-7970)
GPIB Extender (1252-6133)
Table 6-2 Monitors
Part Number Description
2090-0952 DISPLAY LCD 17-IN 1280X1024-PIXELS 377X490X301-MM
Table 6-3 PC Plug-in Cards
Part Number Description
1150-7919 NI GPIB interface
82350-66511 Keysight PCI GPIB INTERFACE
0960-2461 ROCKERPORT UNIVERSAL PCI CARD RS-232/422, 8P, DB25 MALE,
SURGE
1150-7773 32 CHANNEL DIO CARD W2500VDC ISOLATION (PCI IO CARD)
1150-7983 CAN PCI-INTERFACE CARD 2 CHANNEL
Table 6-4 Fixed Power Supplies
Part Number Description
0950-4519 12V/2A Fixed DC Power Supply
0950-4520 24V/1.5A Fixed DC Power Supply
