Keysight TS-5020 - Table 3-17 L2000 (TITAN) Slot 13 to 20 (8-CH Load Card)

3-26 TS-5020 Automotive Electronics Functional Test System Wiring Guide and Hardware Reference
3 System Overview
Table 3-17 L2000 (TITAN) Slot 13 to 20 (8-CH Load Card)
Wiring Table for E6175A
Contact # Signal Contact # Signal Contact # Signal
1
loadcard10x.Ch1
33
No Connection
65
loadcard10w.Ch1
2
No Connection
34
No Connection
66
No Connection
3
loadcard10x.Ch2
35
No Connection
67
loadcard10w.Ch2
4
No Connection
36
No Connection
68
No Connection
5
loadcard10x.Ch3
37
No Connection
69
loadcard10w.Ch3
6
No Connection
38
No Connection
70
No Connection
7
loadcard10x.Ch4
39
No Connection
71
loadcard10w.Ch4
8
No Connection
40
No Connection
72
No Connection
9
loadcard10x.Ch5
41
No Connection
73
loadcard10w.Ch5
10
No Connection
42
No Connection
74
No Connection
11
loadcard10x.Ch6
43
No Connection
75
loadcard10w.Ch6
12
No Connection
44
No Connection
76
No Connection
13
loadcard10x.Ch7
45
No Connection
77
loadcard10w.Ch7
14
No Connection
46
No Connection
78
No Connection
15
loadcard10x.Ch8
47
No Connection
79
loadcard10w.Ch8
16
No Connection
48
No Connection
80
No Connection
17
loadcard10y.Ch1
49
No Connection
81
loadcard10z.Ch1
18
No Connection
50
No Connection
82
No Connection
19
loadcard10y.Ch2
51
No Connection
83
loadcard10z.Ch2
20
No Connection
52
No Connection
84
No Connection
21
loadcard10y.Ch3
53
No Connection
85
loadcard10z.Ch3
22
No Connection
54
No Connection
86
No Connection
23
loadcard10y.Ch4
55
No Connection
87
loadcard10z.Ch4
24
No Connection
56
No Connection
88
No Connection
25
loadcard10y.Ch5
57
No Connection
89
loadcard10z.Ch5
26
No Connection
58
No Connection
90
No Connection
27
loadcard10y.Ch6
59
No Connection
91
loadcard10z.Ch6
28
No Connection
60
No Connection
92
No Connection
29
loadcard10y.Ch7
61
No Connection
93
loadcard10z.Ch7
30
No Connection
62
No Connection
94
No Connection
31
loadcard10y.Ch8
63
No Connection
95
loadcard10z.Ch8
32
No Connection
64
No Connection
96
No Connection
