Keysight TS-5020 - TCn Pinouts

System Interconnects 4
TS-5020 Automotive Electronics Functional Test System Wiring Guide and Hardware Reference 4-13
General TC Pins Assignment
The connections on the TC pins depend on the components that
the user has ordered for the system.
Figure 4-11 TC
n
Pin Assignments
Notes:
[1] Power Bus Sense and I Sense are present only on TC3 and
only if the loadbox is present. Otherwise the pins are not
used.
[2] Spare instrument access pins.
T
C
n
(n = 3, 5, 7)
123456
A
loadcard n.01 loadcard n.02 loadcard n.03 loadcard n.04 loadcard n.05 loadcard n.06
A
B
loadcard n.07 loadcard n.08 loadcard n.09 loadcard n.10 loadcard n.11 loadcard n.12
B
C
loadcard n.13 loadcard n.14 loadcard n.15 loadcard n.16 loadcard n.17 loadcard n.18
C
D
loadcard n.19 loadcard n.20 loadcard n.21 loadcard n.22 loadcard n.23 loadcard n.24
D
E
loadcard n.25 loadcard n.26 loadcard n.27 loadcard n.28 loadcard n.29 loadcard n.30
E
F
loadcard n.31 loadcard n.32 loadcard n.33 loadcard n.34 loadcard n.35 loadcard n.36
F
G
loadcard n.37 loadcard n.38 loadcard n.39 loadcard n.40 loadcard n.41 loadcard n.42
G
H
loadcard n.43 loadcard n.44 loadcard n.45 loadcard n.46 loadcard n.47 loadcard n.48
H
J
Safety Ground Safety Ground Safety Ground Safety Ground Safety Ground Safety Ground
J
K
Digital I/O Digital I/O System Ground
Loadbox PB
S1
[1]
Trigger #1 System Ground
K
L
Digital I/O Digital I/O Not Used
Loadbox PB
S2
[1]
Trigger #2 Not Used
L
M
Digital I/O Digital I/O Not Used
Loadbox PB
S3
[1]
Trigger #3
Loadbox I
sen1
[1]
M
N
Digital I/O Digital I/O Not Used
Loadbox PB
S4
[1]
Trigger #4
Loadbox I
sen2
[1]
N
P
UserAccess 1 UserAccess 2 UserAccess 3 UserAccess 4 Aux Inst #1 Aux Inst #2
P
R
UserAccess 5 UserAccess 6 UserAccess 7 UserAccess 8 System Ground System Ground
R
S
UserAccess Com1 UserAccess Com1 UserAccess Com1 UserAccess Com1 InstAccess#1 [2] InstAccess#2 [2]
S
T
UserAccess 9 UserAccess 10 UserAccess 11 UserAccess 12 InstAccess#3 [2] InstAccess#4 [2]
T
U
UserAccess 13 UserAccess 14 UserAccess 15 UserAccess 16 ARB High [2] ARB Low [2]
U
V
UUT Common n UUT Common n UUT Common n UUT Common n PMatrix n Row 1 PMatrix n Row 2
V
W
PMatrix n Row 3 PMatrix n Row 4 PMatrix n Row 5 PMatrix n Row 6 PMatrix n Row 7 PMatrix n Row 8
W
X
PMatrix n Row 9 PMatrix n Row 10 PMatrix n Row 11 PMatrix n Row 12 PMatrix n Row 13 PMatrix n Row 14
X
Y
UUT Common n UUT Common n UUT Common n UUT Common n UUT Common n UUT Common n
Y
Z
PMatrix n Row 15 PMatrix n Row 16 PMatrix n Row 17 PMatrix n Row 18 PMatrix n Row 19 PMatrix n Row 20
Z
AA
PMatrix n Row 21 PMatrix n Row 22 PMatrix n Row 23 PMatrix n Row 24 PMatrix n Row 25 PMatrix n Row 26
AA
BB
UUT Common n UUT Common n UUT Common n UUT Common n UUT Common n UUT Common n
BB
CC
PMatrix n Row 27 PMatrix n Row 28 PMatrix n Row 29 PMatrix n Row 30 PMatrix n Row 31 PMatrix n Row 32
CC
123456
