Keysight TS-5020 - Table 3-13 L2000 (TITAN) Slot 12 to 15 (GP Relay Card (34939 A))

3-22 TS-5020 Automotive Electronics Functional Test System Wiring Guide and Hardware Reference
3 System Overview
Table 3-13 L2000 (TITAN) Slot 12 to 15 (GP relay Card (34939A))
Contact # Signal Contact # Signal Contact # Signal
1
loadcard00x.Ch1
33
loadcard00x.Ch2
65
loadcard00x.Pwr1-2
2
loadcard00x.Ch3
34
loadcard00x.Ch4
66
loadcard00x.Pwr3-4
3
loadcard00x.Ch5
35
loadcard00x.Ch6
67
loadcard00x.Pwr5-6
4
loadcard00x.Ch7
36
loadcard00x.Ch8
68
loadcard00x.Pwr7-8
5
loadcard00x.Ch9
37
loadcard00x.Ch10
69
loadcard00x.Pwr9-10
6
loadcard00x.Ch11
38
loadcard00x.Ch12
70
loadcard00x.Pwr11-12
7
loadcard00x.Ch13
39
loadcard00x.Ch14
71
loadcard00x.Pwr13-14
8
loadcard00x.Ch15
40
loadcard00x.Ch16
72
loadcard00x.Pwr15-16
9
loadcard00x.Ch17
41
loadcard00x.Ch18
73
loadcard00x.Pwr17-18
10
loadcard00x.Ch19
42
loadcard00x.Ch20
74
loadcard00x.Pwr19-20
11
loadcard00x.Ch21
43
loadcard00x.Ch22
75
loadcard00x.Pwr21-22
12
loadcard00x.Ch23
44
loadcard00x.Ch24
76
loadcard00x.Pwr23-24
13
loadcard00x.Ch25
45
loadcard00x.Ch26
77
loadcard00x.Pwr25-26
14
loadcard00x.Ch27
46
loadcard00x.Ch28
78
loadcard00x.Pwr27-28
15
loadcard00x.Ch29
47
loadcard00x.Ch30
79
loadcard00x.Pwr29-30
16
loadcard00x.Ch31
48
loadcard00x.Ch32
80
loadcard00x.Pwr31-32
17
loadcard00x.Ch33
49
loadcard00x.Ch34
81
loadcard00x.Pwr33-34
18
loadcard00x.Ch35
50
loadcard00x.Ch36
82
loadcard00x.Pwr35-36
19
loadcard00x.Ch37
51
loadcard00x.Ch38
83
loadcard00x.Pwr37-38
20
loadcard00x.Ch39
52
loadcard00x.Ch40
84
loadcard00x.Pwr39-40
21
loadcard00x.Ch41
53
loadcard00x.Ch42
85
loadcard00x.Pwr41-42
22
loadcard00x.Ch43
54
loadcard00x.Ch44
86
loadcard00x.Pwr43-44
23
loadcard00x.Ch45
55
loadcard00x.Ch46
87
loadcard00x.Pwr45-46
24
loadcard00x.Ch47
56
loadcard00x.Ch48
88
loadcard00x.Pwr47-48
25
loadcard00x.Ch49
57
loadcard00x.Ch50
89
loadcard00x.Pwr49-50
26
loadcard00x.Ch51
58
loadcard00x.Ch52
90
loadcard00x.Pwr51-52
27
loadcard00x.Ch53
59
loadcard00x.Ch54
91
loadcard00x.Pwr53-54
28
loadcard00x.Ch55
60
loadcard00x.Ch56
92
loadcard00x.Pwr55-56
29
loadcard00x.Ch57
61
loadcard00x.Ch58
93
loadcard00x.Pwr57-58
30
loadcard00x.Ch59
62
loadcard00x.Ch60
94
loadcard00x.Pwr59-60
31
loadcard00x.Ch61
63
loadcard00x.Ch62
95
loadcard00x.Pwr61-62
32
loadcard00x.Ch63
64
loadcard00x.Ch64
96
loadcard00x.Pwr63-64
