Keysight TS-5020 - Table 5-1 E6170-61626 Cable Pinout Table

Test System Interface Cables 5
TS-5020 Automotive Electronics Functional Test System Wiring Guide and Hardware Reference 5-5
Table 5-1 E6170-61626 Cable Pinout Table
Signal Part
#
Product; Port Connector Cable Connector Product; Port Length
Name E6170- Label) Position Wire Position Label) mm)
61626 PCI-1750 DIO DSUB-37M 1252-3536
Express
Conn; J8
2200
DIO0 11*
1569-20WHT
a7
DIO1 30*
1569-20WHT
c7
DIO2 12*
1569-20WHT
a8
DIO3 31*
1569-20WHT
c8
DIO4 13*
1569-20WHT
a9
DIO5 32*
1569-20WHT
c9
DIO6 14*
1569-20WHT
a10
DIO7 33*
1569-20WHT
c10
DIO8 15*
1569-20WHT
a21
DIO9 34*
1569-20WHT
c21
DIO10 16*
1569-20WHT
a22
DIO11 35*
1569-20WHT
c22
DIO12 17*
1569-20WHT
a23
DIO13 36*
1569-20WHT
c23
DIO14 18*
1569-20WHT
a24
DIO15 37*
1569-20WHT
c24
Jumper (11) to 1*
1569-20WHT
a/r
Jumper (30) to 20*
1569-20WHT
a/r
Jumper (12) to 2*
1569-20WHT
a/r
Jumper (31) to 21*
1569-20WHT
a/r
Jumper (13) to 3*
1569-20WHT
a/r
Jumper (32) to 22*
1569-20WHT
a/r
Jumper (14) to 4*
1569-20WHT
a/r
Jumper (33) to 23*
1569-20WHT
a/r
Jumper (15) to 5*
1569-20WHT
a/r
Jumper (34) to 24*
1569-20WHT
a/r
Jumper (16) to 6*
1569-20WHT
a/r
Jumper (35) to 25*
1569-20WHT
a/r
Jumper (17) to 7*
1569-20WHT
a/r
Jumper (36) to 26*
1569-20WHT
a/r
Jumper (18) to 8*
1569-20WHT
a/r
Jumper (37) to 27*
1569-20WHT
a/r
DIO IGND 9
1569-20BLK
a1
28
1569-20BLK
c1
29
1569-20BLK
c6
Tinned wire (twist together)
+12V
+12VDC; +
strip 10mm, twist & tin*
1569-20RED
a25
(strip 10mm, twi(st & tin)
1569-20RED
c25
(strip 10mm, twi(st & tin)
1569-20RED
a26
+12VRTN
+12VDC; -
strip 10mm, twist & tin*
1569-20BLK
a29
(strip 10mm, twi(st & tin)
1569-20BLK
c29
(strip 10mm, twi(st & tin)
1569-20BLK
a28
(twist together)
-12V
-12VDC; -
strip 10mm & trim
1569-20BLK
a27
-12VRTN
-12VDC; +
strip 10mm & trim
1569-20RED
c28*
(twist together)
SpareV
Vspare;+
strip 10mm & trim
1569-20RED
c27
SpareVRTN
Vspare;-
strip 10mm & trim
1569-20BLK
(c28)
