Keysight TS-5020 - Table 5-3 E6170-61629 Cable Pinout Table

Test System Interface Cables 5
TS-5020 Automotive Electronics Functional Test System Wiring Guide and Hardware Reference 5-9
Table 5-3 E6170-61629 Cable Pinout Table
Signal Part # Product; Port Connector Cable Connector Product; Port Length
Name E6170- Label Position Wire Position Label (mm)
61629
34938A Bank 1 DSUB-50F (1 of 2)
Molex 39-01-2245 (2
total)
1000
Ch1 3 1569-20WHT LoadcardA.12 LOADCARD A
Ch1.Com 4 1569-20WHT LoadcardB.24 LOADCARD B
Ch2 7
1569-20WHT
LoadcardA.11
Ch2.Com 8 1569-20WHT LoadcardB.23
Ch3 9 1569-20WHT LoadcardA.10
Ch3.Com 10
1569-20WHT
LoadcardB.22
Ch4 13
1569-20WHT
LoadcardA.9
Ch4.Com 14 1569-20WHT LoadcardB.21
Ch5 15 1569-20WHT LoadcardA.8
Ch5.Com 16
1569-20WHT
LoadcardB.20
Ch6 1 1569-20WHT LoadcardA.7
Ch6.Com 2 1569-20WHT LoadcardB.19
Ch7 5
1569-20WHT
LoadcardA.6
Ch7.Com 6
1569-20WHT
LoadcardB.18
Ch8 39 1569-20WHT LoadcardA.5
Ch8.Com 40 1569-20WHT LoadcardB.17
Ch9 11
1569-20WHT
LoadcardA.4
Ch9.Com 12 1569-20WHT LoadcardB.16
Ch10 47 1569-20WHT LoadcardA.3
Ch10.Com 48
1569-20WHT
LoadcardB.15
34938A Bank 2 DSUB-50F (2 of 2)
Ch11 3
1569-20WHT
LoadcardA.2
Ch11.Com 4
1569-20WHT
LoadcardB.14
Ch12 7 1569-20WHT LoadcardA.1
Ch12.Com 8 1569-20WHT LoadcardB.13
Ch13 9
1569-20WHT
LoadcardA.13
Ch13.Com 10 1569-20WHT LoadcardB.1
Ch14 13 1569-20WHT LoadcardA.14
Ch14.Com 14
1569-20WHT
LoadcardB.2
Ch15 15
1569-20WHT
LoadcardA.15
Ch15.Com 16 1569-20WHT LoadcardB.3
Ch16 1 1569-20WHT LoadcardA.16
Ch16.Com 2
1569-20WHT
LoadcardB.4
Ch17 5 1569-20WHT LoadcardA.17
Ch17.Com 6 1569-20WHT LoadcardB.5
Ch18 39
1569-20WHT
LoadcardA.18
Ch18.Com 40
1569-20WHT
LoadcardB.6
Ch19 11 1569-20WHT LoadcardA.19
Ch19.Com 12 1569-20WHT LoadcardB.7
Ch20 47
1569-20WHT
LoadcardA.20
Ch20.Com 48 1569-20WHT LoadcardB.8
(twist together)
PS+ PS; + AMP-321233* 1569-20RED LoadcardB.10 2000
(AMP-321233) 1569-20RED LoadcardB.11
(AMP-321233)
1569-20RED
LoadcardB.12
PS-
PS; -
AMP-321233*
1569-20BLK
LoadcardA.22
(AMP-321233) 1569-20BLK LoadcardA.23
(AMP-321233) 1569-20BLK LoadcardA.24
(twist together)
PSSense+ PS; Sense+ (strip 10mm & tin) 1569-20RED LoadcardB.9
PSSense-
PS; Sense-
(strip 10mm & tin)
1569-20BLK
LoadcardA.21
