Keysight TS-5020 - Connecting Wiring to Test Connectors TC1- TC8

System Interconnects 4
TS-5020 Automotive Electronics Functional Test System Wiring Guide and Hardware Reference 4-3
Connectors and Tools
The specialized connectors and tools referenced in this chapter
are available from Keysight as these options/part numbers:
• Keysight E6244A Option 001--Contains two 156-pin, ITT
Cannon Zero-Insertion-Force mating connectors.
• Keysight E6244A Option 013--Crimp tool for Cannon
connector contacts.
• Keysight E6244A Option 014--Extraction tool for Cannon
connector contacts.
• Keysight E6244A Option 020--High Power Mating
Connector Kit.
• Keysight E6244A Option 024--Extraction tool for Hi Power
Connectors.
Standard connectors should be acquired from your local
electronic parts supplier.
Connecting Wiring to Test Connectors TC1- TC8
The figures on this and the following pages show how to connect
wiring and assemble the mating connectors for Test Connectors
TC1 through TC8. Should you make a mistake,
Figure 4-3 shows
how to remove a contact from a connector. Each Test
Connector contact is rated at 3A (continuous).
CAUTION
Use only the Keysight supplied connector kit with its
non-conductive handle screw. Failure to use the Keysight
supplied kit may void the warranty.
