Keysight x-series Measurement Guide

30
Measuring Multiple Signals
Resolving Signals of Equal Amplitude
Figure 2-6 Unresolved Signals of Equal Amplitude
8 Decrease the RBW. • Press BW, Res BW, 10, kHz. Two signals are now visible, see
Figure 2-7. You can use the
front-panel knob or step keys to
further reduce the resolution
bandwidth and better resolve
the signals.
Step Action Notes

Keysight x-series Specifications

General

Analysis Bandwidth	Up to 1 GHz (depending on model)
Real-Time Bandwidth	Up to 1 GHz (depending on model)
Form Factor	Benchtop
Connectivity	LAN, USB, GPIB
Resolution Bandwidth	1 Hz to 10 MHz (depending on model)
