177
Option Esc External Source Control
Using Option ESC with the Keysight MXG Signal Sources.
Lan
The X-Series with Option ESC controls the MXG through a LAN connection based
on TCP/IP protocol. The TCP/IP protocol can only be established with correct IP
addressing.
NOTE You must be logged in as an Administrator to change the TCP/IP properties. This
requires the use of a USB mouse and keyboard.
X-Series Instrument
NOTE Assure only ONE correction file is turned on because it is possible to turn on
multiple correction files, and if some of the files share the same frequency points, the
correction that results for those shared frequency points will cause measurement
errors. Therefore assure that only the correction file required for the measurement is
turned on, and turn off all other corrections.
Loading conversion loss data for the PXA Signal Analyzer
The conversion loss data supplied with your mixer can be loaded into your signal
analyzer from one of two sources:
8 Turn on the Signal ID
function
• Press Input Output, External
Mixing, Signal ID Mode, Image
Suppress, Signal ID On.
This enables you to identify true
signals from images and
harmonics.
See “Signal ID” on page 182
for more information.
Step Action Notes
Step Action
1 Log off as default user. •Click Start, Log Off, Log Off
2 Log on as an administrator. • At the log in prompt enter:
User name: administrator
Password: agilent4u
3 Assign an IP adress and a subnet mask.
