Safety features of your vehicle Seat
To raise the headrest, pull it up to
the desired position (1). To lower
the headrest, push and hold the
release button (3) on the headrest
support and lower the headrest to
the desired position (2).
Removal (2nd and 3rd row seat)
To remove the headrest, raise it as
far as it can go then press the
release button (1) whilst pulling the
headrest up (2).
To reinstall the headrest, put the
headrest poles (3) into the holes
whilst pressing the release button
(1). Then adjust it to the appropri
-
ate height.
Make sure the headrest locks in
position after adjusting it to prop
-
erly protect the occupants.
Armrest (if equipped)
To use the armrest, pull it forward
from the seatback.
Armrest adjustment (2nd row seat,
for 6 passenger vehicle) (if
equipped)
Adjustable armrest is located on
each side of 2nd row seatback. To
use the armrest, pull it forward
from the seatback and adjust to
desired angle. Pull it backward to
relocate the armrest.
