Maintenance
547
Wiper blades
For your convenience, move the
windscreen wiper blades to the ser
-
vice position as follows;
After turning off the engine, move
the wiper switch to the single wiping
(MIST) position within 20 seconds
and hold the switch more than 2
seconds until the wiper blade is in
the fully up position.
Do not allow the wiper arm to fall
against the windscreen, since it may
chip or crack the windscreen.
1. Raise the wiper arm.
2. Lift up the wiper blade clip. Then
pull down the blade assembly and
remove it.
3. Install the new blade assembly.
4. Return the wiper arm on the
windscreen.
5. Turn ignition to the ON position
and wiper arms will return to the
normal operating position.
Replacing rear wiper blade
Move the rear wiper to the bottom
middle part, and lift up the wiper
arm. Pull the wiper blade to remove
it.
