6-30 Applied Operation PLZ-4W
Table6-4 Setup items on each setup screen
Edit screen Setup item Description
Program operation
No. Program number (11)
Memo Memo (11 characters)
Mode Operation mode (CC or CR)
Range Range setting (Current range - Voltage range)
Loop
Number of program loops
(1 to 9999) 9999 is infinite loop
Last Load
Load condition after the end of the sequence
(ON/OFF)
Last Set
Current value after the end of the sequence
(0.000 to 100 % of the range setting)
RPTSTEP Last step number (3 to 1024) per loop
TIME BASE Step execution time (25 s to 100 ms)
FILL
DATA1
Current for the start step
(0.000 to 100 % of the range setting)
DATA2
Current for the end step
(0.000 to 100 % of the range setting)
START Start step number
STOP End step number
Trigger signal TRIG Trigger output (ON/OFF)
Magnification M1,2,3,4,5,6,7,8 The value indicates the number of skipped steps.
