PLZ-4W Basic Operation 5-3
5.2 Turning On or Off the Load
“Turning on the load” refers to the operation of supplying current to the PLZ-4W.
“Turning off the load” refers to the operation of cutting off the current to the PLZ-
4W. The LOAD key is used to turn on or off the load. Please remember the expres-
sion “turning on the load” and “turning off the load”, as they are used frequently in
this manual.
• When the step-by-step procedure to turning on/off the load was incorrectly
performed, it may cause the damage to the PLZ-U. Be sure to follow the
procedure as instructed to turning on/off the load.
Load On
1. Check that load is turned off.
2.
Apply the output of the DUT to the input of the PLZ-U. In case the relay
or the electromagnetic switch is used for the connection between the
load input terminal and the output terminal of the DUT, turn on the relay
or the electromagnetic switch.
3.
Press the LOAD key to turn on the load.
Load Off
1. Press the LOAD key to turn off the load.
2.
Turn off the output of the DUT. In case the relay or the electromagnetic
switch is used for the connection between the load input terminal and
the output terminal of the DUT, turn on the relay or the electromagnetic
switch.
Functions related to turning on or off of the load
The PLZ-4W provides the following functions related to the turning on or off of the
load.
■ Starting with the load turned on
By factory default, the load is not turned on unless you press the LOAD key after
turning on the POWER switch.
If you select “2. Configuration” | “2. Power On” from the menu and set the Load On
setting to on, the load is turned on when you turn on the POWER switch.
• For a description of changing the menu setup, see section 5.13, “Menu Setup.”
