2-10 Installation and Preparation PLZ-4W
2.8 Load Wiring
To ensure that the functions of the PLZ-4W work accurately and reliably, all wires
must be connected correctly to their loads.
• This operation manual refers to the terminal on the rear panel to which the equip-
ment under test is connected and current is supplied as load input terminal.
2.8.1 Precautions Concerning Wiring
Electric wire used
• Use a load wire with sufficient diameter for the current as well as non-flam-
mable or flame-resistant cover.
If the resistance of the load wire is large, a large voltage drop may occur when a cur-
rent is supplied and the voltage at the load input terminal may fall below the minimum
operating voltage. Refer to Table 2-1 and select thick wires as much as possible.
Table2-1 Nominal cross-sectional area of wires and allowable currents
Nominal Cross-
Sectional Area
[mm
2
]
AWG
(Reference Cross-
Sectional Area)
[mm
2
]
Allowable Current(*)
[A]
(Ta = 30 C)
Kikusui-Recom-
mended Current
[A]
2 14 (2.08) 27 10
3.5 12 (3.31) 37 -
5.5 10 (5.26) 49 20
8 8 (8.37) 61 30
14 6 (13.3) 88 50
22 4 (21.15) 115 80
30 2 (33.62) 139 -
38 1 (42.41) 162 100
50 1/0 (53.49) 190 -
60 2/0 (67.43) 217 -
80 3/0 (85.01) 257 200
100 4/0 (107.2) 298 -
125 - - 344 -
150 - - 395 300
200 - - 469 -
250 - - 556 -
325 - - 650 -
*Excerpts from Japanese laws related to electrical equipment.
