1.5 Overview of Controls
This section describes the controls on the electronic load and combined systems.
Operation using the control panel
The PLZ-4W employs a large LCD. Measured values of voltage, current, and power
at the load input terminal are indicated at all times. The values are indicated using
larger characters than other sections to improve the visibility.
Coarse and fine adjustments using the rotary knob are useful for setting values over
a wide range.
Fig.1-1 Panel control
External communication interface
The PLZ-4W can be controlled from a PC.
GPIB, RS232C, and USB communication functions come standard.
Fig. 1-2 PLZ-4W and PC connection diagram
