PLZ-4W Basic Operation 5-27
Table5-2 Menu items
*1:Underlined values are factory default values.
Menu name 1 Menu name 2 Item name Values <*1>
1. Setup 1. Function Soft Start 1 ms
, 2 ms, 5 ms, 10 ms, 20 ms,
50 ms, 100 ms, 200 ms
Count Time (elapsed time display) OFF
, ON
2. Protect Action OCP LIMIT
, LOAD OFF
OPP LIMIT, LOAD OFF
3. Memory ABC Preset Memory Recall SAFETY
, DIRECT
4. Cut Off Time (auto load off timer) OFF
, 000:00:01 to 999:59:59
5. Response – 1/1, 1/2, 1/5, 1/10
2. Configura-
tion
1. Master/Slave Operation MASTER
, SLAVE
Parallel (MASTER only) -
, 2, 3, 4, 5
Load booster (MASTER: PLZ1004W only) -, 1, 2, 3, 4
2. Power On
Load On
OFF
, ON
Key Lock
OFF, ON
3. Interface Control GPIB, RS232C, USB
GPIB Address 1
to 30
RS232C Baudrate 2 400, 4 800, 9 600, 19200 bps
Data 8 (fixed)
Stop 1, 2
Parity NONE
Ack (acknowledge) OFF
, ON
USB VID 0x0B3E (display only)
PID xxxx (display only)
S/N xxxx (display only)
4. External Control OFF
, V, R, Rinv (Inverse)
LoadOn IN LOW, HIGH
3. Calibration 1. CC (Low)
To the calibration screen (see chapter 8, “Maintenance and Calibration.”)
2. CC (Mid)
3. CC (High)
4. CV 15V
5. CV 150V
4. Model info MODEL (Model) PLZxxxW
VERSION SUB (Firmware version) x.xx
VERSION MAIN (ROM version) x.xx
To Next Page
