Kinco SV100 Series User Manual

9
Tabble 2-2 Mechanical parameters
VFD model
（G：Constant torque
load;
L: Draught fan and
water pump load）
External dimension and (mm)
Weigh
t (kg)
W
H
D
W1
H1
D1
T1
Installation
hole(d)
SV100-2S-0004G
115
186
169
104
174
12
7
5
1.5
SV100-2S-0007G
SV100-2S-0015G
SV100-2S-0022G
SV100-4T-0007G
SV100-4T-0015G
SV100-4T-0022G
SV100-4T-0037G
SV100-4T-0055G
167
291
201
102
277
80
2
5.5
4.5
SV100-4T-0075G
SV100-4T-0110G
202
342
200
140
328
82
2
7
6.5
SV100-4T-0150G
SV100-4T-0185G
289
440
223
200
424
89
2.5
7
17
SV100-4T-0220G
SV100-4T-0300G
315
534
224
220
516
88.5
2.5
7
25
SV100-4T-0370G
SV100-4T-0450G
371
649
262
240
672
108
2.5
10
30
SV100-4T-0550G
SV100-4T-0750G
438
717
277
270
692
120
3
10
35
SV100-4T-0900G
