4-7
. Remove the control knob. Remove the
thermostat control by rotating the back of the
thermostat up and out of the control box.
10.Pull the thermostat bulb through the liner into
the component compartment from the back
of the unit.
Remove the base grill. (See page 4-13)
Remove the two screws that secure the Con-
trol box to the bottom of the unit.
Lower the front of the control box and slide
the rear tabs out of the slots that hold the
back of the control box.
6.
7.
8.
9.
Tabs
Screws
To Next Page
