4-26
The Beverage Center has 3 separate temper-
ature zones for cooling.
The top section with one half glass shelf and
one full glass shelf
The mid section, one rack above the separa-
tor and below the full glass shelf.
The lower section with two racks below the
separator.
To remove the glass shelves, lift and pull the
shelf out as one piece.
•
•
•
•
REMOVE DOOR GASKET
Open the door of the unit.
Starting at one of the corners, carefully pull
the gasket away from the door. Allow the
rubber tab to slide out of the channel in the
door.
Replace the gasket by starting at one of the
corners and pressing the rubber tab of the
new gasket into the channel in the door.
Work your way around the door in one con-
tinuous direction until finished.
1.
2.
3.
BEVERAGE CENTER
LAYOUT (BC)
Top Section
Mid Section
Lower Section
