Section 8
High Pressure Water System
20425618
5-2005/Rev 0
8-39
Table 8-3
Weep Holes
High Pressure Water System
Location Indication Comments
Sealing Head
Make sure the gland nut is
tightened to the proper torque
specification.
Seat in the discharge check valve
is not sealing properly
Inspect the seat, sealing head and
gland nut for scratches, erosion or
cracks.
Internal crack in sealing head Replace the sealing head.
A cracked sealing head can result
in water leaking from the high
pressure outlet passage to the low
pressure inlet passages.
The sealing head body can
become extremely hot.
Improper torque on gland nut Tighten the gland nut to the
proper torque specification.
Water leaking from the weep
hole in the sealing head
Erosion or scratches on the
contact surface of the sealing
head, or on the gland nut where
the seat makes contact
Polish the surfaces following the
procedure, Sealing Head
Maintenance.
High pressure piping gland nut is
not tight and is not sealing
properly
Tighten the gland nut to the
proper torque specification.
Check the number of exposed
threads past the collar on the high
pressure piping. Only 1-1/2 to 2-
1/2 threads should be exposed.
Check high pressure piping for
damage, cracks or deformation.
Improper high pressure piping
connection
Inspect the gland nut for
deformation of the threads.
Water leaking from the weep
hole in the gland nut
Damaged sealing head gland nut Check the gland nut for cracks
due to fatigue. If cracks are
detected, replace the gland nut.
To Next Page
