Section 10
Specifications
20425644
5-2005/Rev 0
10-10
Torque Specifications
Sealing Head
Discharge Gland Nut 130 ft-lbs (176 Nm)
Poppet Retainer 25-30 in-lbs (2.8-3.4 Nm)
Pneumatic Control Valve
3/8-inch HP Inlet Gland Nut 50 ft-lbs (68 Nm)
1/4-inch Outlet to Drain 25 ft-lbs (34 Nm)
Pneumatic Actuator 5 ft-lbs (7 Nm)
9/16”-1/4” HP Adapter 50 ft-lbs (68 Nm)
High Pressure Fittings
1/4-inch Gland Nut 25 ft-lb (34 Nm)
3/8-inch Gland Nut 50 ft-lb (68 Nm)
9/16-inch Gland Nut 110 ft-lb (149 Nm)
