KMT STREAMLINE S30 User Manual

Section 11
Parts List
20425652
5-2005/Rev 0
11-18
Table 11-8
Motor/Pump Assembly
80076441
Item
Part
Number Description Quantity
1 80076995 Coupling, Flexible Drive, Motor Shaft 1
2 80077001 Flexible Drive Coupling Insert 1
3 05101605 Vibration Isolation Mount 2
4 80076599 Electric Motor, 30 HP 1
5 80077019 Flange, Motor/Pump Adapter 1
6 95716882 Hex Head Screw, 1/2-13 x 1-1/4 2
7 05083258 Piston Pump, 3100 psi, 45 cc 1
8 05037593 Socket Head Screw, M10 x 1.50 x 25 MM 2
9 10069714 Flat Washer, 0.38 x 0.078 2
10 10069763 Flat Washer, 0.50 x 0.109 2
11 05073168 Elbow, JIC/O-Ring, 45D 1
12 05045364 Gear Pump, Double Shaft 1
13 80077027 Coupling, Flexible Drive, Spline 1
14 05114087 Socket Head Screw, 3/8-16 x 1.38 3
15 95070132 Hex Head Screw, 5/8-11 x 1-1/2 4
16 10134989 Flat Washer, 0.63 4
