KMT STREAMLINE S30 User Manual

Section 11
Parts List
20425652
5-2005/Rev 0
11-20
Table 11-9
Hydraulic Manifold Assembly
05142187
Item
Part
Number Description Quantity Item
Part
Number Description Quantity
1 05142179 Manifold 1 12 95391322 Flat Washer, 0.25 x 0.063 2
2 05139936 Directional Control Valve 1 13 05142294 Pressure Gauge, 0-5000 1
3 05140785 Bolt Kit, Directional Control Valve 1 14 05129689 Plug, O-Ring, Hex Socket, 0.50 1
4 05071717 Relief Valve Cartridge 1 15 95838314 Lock Washer, 0.25 x 0.063 2
5 05122650 Plug, Hex Socket, 0.63, O-Ring 6 16 05140942 Socket Head Screw, 1/4-20 x 3-1/4 2
6 10192813 Plug, O-Ring, 0.25 1 17 05142302 Adapter, O-Ring/Pipe, 6-4 1
7 05140397 Hydraulic Check Valve Cartridge 1 18 05142393 Socket Head Screw, M10 x 1.50 x 75 MM 8
8 05140819 Flat Washer, M14 x 5 1 19 05061486 Lock Washer, M10 8
9 05140520 Hi/Lo Solenoid Valve 1 20 10087294 Split Flange Kit, 0.75, 5000 psi 2
10 10187052 Relief Valve Knob, 100/3000 psi 1 21 49876089 Adapter, JIC/O-Ring 2
11 05141072 Adapter, JIC/Split Flange, 12-12, 45D 1 22 10144749 Adapter, JIC/O-Ring, 45D, 4-4 1
