Section 8
High Pressure Water System
20425618
5-2005/Rev 0
8-8
Table 8-1
Torque Specifications
High Pressure Water System
Proximity Switch
Socket Head Screws 2 (M6) each
Torque 140-160 in-lbs (16-18 Nm)
Hex Key M5
Sealing Head
Discharge Gland Nut 130 ft-lbs (176 Nm)
Poppet Retainer 25-30 in-lbs (2.8-3.4 Nm)
Optional Pneumatic Control Valve
3/8” HP Inlet Gland Nut 50 ft-lbs (68 Nm)
1/4” Outlet to Drain 25 ft-lbs (34 Nm)
Pneumatic Actuator 5 ft-lbs (7 Nm)
9/16”-1/4” HP Adapter 50 ft-lbs (68 Nm)
