Koden CVS-128 - Page 77

Chapter 6 Table Attached CVS-128/128B
6-2 0093112802-06
[MENU] key
A
djus
t
Image speed (Speed1, Speed2, Speed3, Speed4, Stop, Speed5 (1/1), Speed6, Speed7,
Speed8, Speed9)
IR (OFF, Weak, Strong : Strong (For CVS-128) , Weak (For CVS-128B))
Color rejection (0 to 50 %: 0%)
Noise rejection (0 to 10: 0)
TX power (20, 30, 40, 50, 60, 70, 80, 90, 100, Auto)
Shift step (1m, 10m, 1/8, 1/4)
Zoom type (Bottom, Bottom Discrimination, Zoom, Bottom Zoom, Bottom Follow Zoom)
Zoom range (2.5 to 200 m: 10.0 m)
Zoom start (0 to 800 m: 0m)
Disp width (Left2, Left1, Center, Right1, Right2)
D.range
Inner-hull : No
Range 1 (2.5 to 1200 m: 5.0)
Range 2 (2.5 to 1200 m: 10.0)
Range 3 (2.5 to 1200 m: 20.0)
Range 4 (2.5 to 1200 m: 50.0)
Range 5 (2.5 to 1200 m: 100)
Range 6 (2.5 to 1200 m: 160)
Range 7 (2.5 to 1200 m: 300)
Range 8 (2.5 to 1200 m: 500)
Range prese
t
A scope (OFF, ON)
White line (OFF, 1, 2, 3, 4, 5, Auto)
Background color (Pale blue, Marine blue, Blue, Dark blue, Black, Darkkhaki,
Mediumseagreen, Light grey, White, Night mode)
Color tone (Monochrome, 8 color, 16 color, 64 color)
Depth value (OFF, Small, Middle, Large)
Display1
Water temp graph (OFF, ON)
Fish symbol (OFF, Symbol 1 to Symbol 10)
Symbol info (OFF, Depth, Size, Bottom<=>Fish)
A
Detection area (OFF, ON)
Scale display (OFF, One, All)
Scale (Small, Middle, Large)
Image direction (←|← , →|→ , ←|→)
Color table1 (Header information, Header BG color, VRM, Depth, Scale,
Scale line,Detection area H, Detection area L)
Display2
Color table2 (Symbol info, Menu BG color, Big fish color, Bottom color)
Bottom detection (Auto, High frequency, Low frequency)
TVG (Weak, Medium, Strong)
Scale type (0, 1)
Big fish (20 to 90: 50)
Pulse width (Super short, Short, Middle, Long) (For CVS-128B)
Band width (Super narrow, Narrow, Middle) (For CVS-128B)
Unit display (OFF, ON)
Freq display (OFF, ON) (For CVS-128B)
Inner-hull : Yes
Range 1 (2.5 to 1200 m: 5.0)
Range 2 (2.5 to 1200 m: 10.0)
Range 3 (2.5 to 1200 m: 20.0)
Range 4 (2.5 to 1200 m: 50.0)
Range 5 (2.5 to 1200 m: 80)
Range 6 (2.5 to 1200 m: 100)
Range 7 (2.5 to 1200 m: 160)
Range 8 (2.5 to 1200 m: 200)
Inner-hull : No
H: 0, L: 0
Inner-hull : Yes
H: 15, L: 30
Gain (TD) (-50 to 50)
D.Range (12dB to 30dB: 24dB) (For CVS-128B)
