Bottom alarm (OFF, ON)
Upper depth (0 to 800 m: 5 m)
Lower depth (1 to 800 m: 50 m)
Fish alarm (OFF, ON)
Position (0 to 800 m: 5 m)
Alarm 1
Range (1 to 800 m: 50 m)
Level (Weak, Medium, Strong)
Water temp alarm (OFF, ON (Inside), ON (Outside))
Upper temp alarm (- 5 to 45.0 °C: 20.0 °C)
Lower temp alarm (- 5 to 45.0 °C: 15.0 °C)
Speed alarm (OFF, ON (Upper), ON (Lower))
Speed limit (0 to 80 kn: 0 kn)
Alarm 2
Arrival alarm (OFF, ON)
XTE alarm (OFF, ON)
NAV alarm range (5 to 999 m: 10 m)
NAV start (No.1 to No.10)
NAV cancel (Yes, No)
WPT edit (No.1 to No.10)
WPT delete (No.1 to No.10)
Background color (OFF, White, Black)
NA
V
NAV 1 (Normal (H), Zoom (H), Dual freq, Zoom (L), Normal (L))
NAV 2 (Normal (H), Zoom (H), Dual freq, Zoom (L), Normal (L))
A
Image swap (A|B, B|A)
Image recall (No.1 to No.10)
Image comment (No.1 to No.10)
Image delete (No.1 to No.10)
EVENT key set (Store pos, Store image, Fishing hot spot)
F1 key set (Image speed, IR, Color rejection, Noise rejection, Shift, Zoom range,
Zoom start, A scope, White line, Background color, Disp width,
NAV start, NAV 1, NAV 2, Image swap, Image recall, Sona-ton)
Operation guide (OFF, ON)
System
F2 key set (Image speed, IR, Color rejection, Noise rejection, Shift, Zoom range,
Zoom start, A scope, White line, Background color, Disp width,
NAV start, NAV 1, NAV 2, Image swap, Image recall, Sona-tone)
B
Sona-tone (OFF, ON)
Key loc
k
Image partition ( , )
Fish image (A|B, A| , |B)
Freq
Freq select (L) (24.0 to 210.0 kHz : 42.0) (For CVS-128B)
Freq select (H) (24.0 to 210.0 kHz : 210.0) (For CVS-128B)
Power freq adj (100.0 to 130.0 : 107.0) (For CVS-128B)
