Komatsu 830E - Page 168

E2-12 Electrical Propulsion Components 2/02 E02016
TABLE I. 2-DIGIT DISPLAY PANEL CODES (Cont.)
EVENT
CODE
EVENT
DESCRIPTION
EVENT RESTRICTION
DETECTION
INFORMATION
EVENT VALUES
Decay
Time
Lock
Limit
Accept
Limit
Window
Limit
12
MF Contactor
System Event
• In ACCEL: No propel and
turn on SYSFLT light.
• In RETARD: Turn on SYS-
FLT light only.
MF Contactor command and
feedback do not agree.
Check for: Same as No. 10.
3600 3 10 2
13
P1 Contactor
System Event
• In ACCEL: No propel and
turn on SYSFLT light.
• In RETARD: Turn on SYS-
FLT light only.
P1 Contactor command and
feedback do not agree.
Check for: Same as No. 10.
3600 3 10 2
14
P2 Contactor
System Event
• In ACCEL: No propel and
turn on SYSFLT light.
• In RETARD: Turn on SYS-
FLT light only.
P2 Contactor command and
feedback do not agree.
Check for: Same as No. 10.
3600 3 10 2
17
RP1 Contactor
System Event
• In ACCEL: No propel and
turn on SYSFLT light.
• In RETARD: Turn on SYS-
FLT light only.
RP1 Contactor command
and feedback do not agree.
Check for: Same as No. 10.
3600 3 10 2
18
RP2 Contactor
System Event
• In ACCEL: No propel and
turn on SYSFLT light.
• In RETARD: Turn on SYS-
FLT light only.
RP2 Contactor command
and feedback do not agree.
Check for: Same as No. 10.
3600 3 10 2
19
RP3 Contactor
System Event
• In ACCEL: No propel and
turn on SYSFLT light.
• In RETARD: Turn on SYS-
FLT light only.
RP3 Contactor command
and feedback do not agree.
Check for: Same as No. 10.
3600 3 10 2
20
RP4 Contactor
System Event
• In ACCEL: No propel and
turn on SYSFLT light.
• In RETARD: Turn on SYS-
FLT light only.
RP4 Contactor command
and feedback do not agree.
Check for: Same as No. 10.
3600 3 10 2
21
RP5 Contactor
System Event
• In ACCEL: No propel and
turn on SYSFLT light.
• In RETARD: Turn on SYS-
FLT light only.
RP5 Contactor command
and feedback do not agree.
Check for: Same as No. 10.
3600 3 10 2
22
RP6 Contactor
System Event
• In ACCEL: No propel and
turn on SYSFLT light.
• In RETARD: Turn on SYS-
FLT light only.
RP6 Contactor command
and feedback do not agree.
Check for: Same as No. 10.
3600 3 10 2
23
RP7 Contactor
System Event
• In ACCEL: No propel and
turn on SYSFLT light.
• In RETARD: Turn on SYS-
FLT light only.
RP7 Contactor command
and feedback do not agree.
Check for: Same as No. 10.
3600 3 10 2
