E2-58 Electrical Propulsion Components 2/02 E02016
TRUCK SPECIFIC INFORMATION
To quickly review the various options on the current
truck, the TRUCK SPECIFIC INFORMATION MENU
can be used to view configuration options, speed set-
tings, serial numbers, etc. Information accessed
through this menu is for viewing only and cannot be
changed. If changes are required, use the “TRUCK
SETUP (CFG)” selection from the GE OHV STATEX III
MENU.
Selecting “SPECIAL OPERATION” in the following
procedure may present a safety hazard if the
engine is running. Control of the propulsion sys-
tem may transfer to the PTU operator from the
truck driver with this software operation. Refer to
Step 1. below:
1. With the GE STATEX III PTU MAIN MENU dis-
played, select “SPECIAL OPERATION” and
press [ENTER]. The screen shown in Figure 2-26
will be displayed to alert the operator about the
state of the truck software.This warning notifies
the operator when control of the truck is being
transferred from the truck driver to the PTU,
based on the PTU selection of “SPECIAL OPER-
ATION”. When finished and the PTU is returned
to the GE STATEX III PTU MAIN MENU, control
of the propulsion system is returned to the truck
driver. Before activating this command, the
screen shown in Figure 2-27 will be dis-
played.The PTU user should always keep the
truck driver appraised of this control.
2. Select “YES” on the caution screen (Figure 2-26)
and press [ENTER]. The SPECIAL OPERATION
MENU will be displayed.
3. Use the arrow keys to move the cursor to the
“TRUCK SPECIFIC INFORMATION MENU”
selection and press [ENTER].
Selections available on this menu are:
• “VIEW OEM CONFIGURATION OPTIONS”
This selection permits reviewing the setup informa-
tion programmed into the truck configuration file by
Komatsu. (These options cannot be changed by
mine personnel.)
• “VIEW MINE CONFIGURATION OPTIONS”
This selection displays options set by mine person-
nel when the truck configuration file was setup for a
specific truck.
• “VIEW SPEED SETTINGS”
This selection allows viewing the current speed
settings contained in the configuration file.
• “VIEW SERIAL AND MODEL NUMBERS”
This selection permits verification of component
serial and model numbers.
• “VIEW GE VERSION INFORMATION”
This selection lists the truck ID number, model
number, and applicable filenames. This screen
also lists the GE code version number and CFG
version number. This information can be useful in
determining whether or not the software has been
updated to the latest release version.
• “VIEW GE PRODUCT SERVICE DATA”
This selection lists information pertinent to the spe-
cific truck.
• “EXIT”
Select “EXIT” to leave the TRUCK SPECIFIC
INFORMATION MENU and return to the GE
STATEX III PTU MAIN MENU.
Selection of NORMAL OPERATION gives truck control
to the driver.
Continue? ( ) Yes
( ) No
OR
Selection of SPECIAL OPERATION will override truck
driver controls until you exit to the PTU main menu.
Continue? ( ) Yes
( ) No
FIGURE 2-26. CAUTION SCREEN
Return to PTU Main Menu gives truck control to the
driver. CAUTION: Contactors may move!
Continue? ( ) Yes
( ) No
FIGURE 2-27. CAUTION SCREEN
